Carousels: <b:carousel>

<b:carousel> allows you to show a slide show. On the other hand, you can also implement a wizard using <b:carousel> .

Basic usage

Basically, just put one or more <b:carouselItem /> inside a <b:carousel /> tag:

Advanced usage: Wizards

You can put arbitrary content inside Carousel items. For instance, you can create a wizard using the carousel. Chances are you need custom controls in this case. We'll hava a look to custom controls in a minute. First, let's see how the standard controls look in a wizard. Don't forget to switch off the animation by setting startAnimation="false". You may also want to set wrap="false" to prevent the wizard to start over after the last step.

In this example, th Buttons use the Bootstrap carousel JavaScript API. It's available for you. You just have to be careful with the ids. More often than not, JSF generates ids that aren't compatible with jQuery. Better use CSS pseudo classes instead (i.e. CSS classes that don't bear layout information).

To send the form data to the Java bean, use the AJAX api of <b:commandButton />

This also allows you to skip slides. Add an invisible input field to your form, update it with the index of the next slide and call $('.wizardPseudoClass').carousel($('invisibleFieldId').val());:

Advanced usage: Captions

Assign an image description to the slides by adding the caption attribute. This provides some default behavior: the text is embedded in an <h3 /> tag. If you need more flexibility for your caption, your can define it inside a <b:carouselCaption /> tag.

Advanced usage: Custom controls

By default, the BootsFaces carousel comes complete with progress indicators (the little dots) and controls to move to the previous or next slide.

You can switch off the indicators by adding showIndicators="false". Apart from that, BootsFaces doesn't let you modify the indicators (unless you use CSS, of course).

The controls are more flexible. You can implement your own custom controls using the tag <b:carouselControl />. Note that the CSS class "carousel-control" add a shadow to the left and to the right of the image, and positions the control widgets automatically. If you don't want to use the CSS class "custom-control" - as we did in the wizard demo above - you have to care about positioning yourself.

Also note that you need to add at least two <b:carouselControls />, one for each direction.

AJAX and JavaScript since 0.8.0

<b:carousel > supports many JavaScript and AJAX events, as described in the description of AJAX in BootsFaces. Basically, each of the many JavaScript callback handlers (the on[event] attributes) also supports AJAX. Plus, it also supports the events "slideStart" when the transition to the next starts begins, and "slid" when the transition has completed. Note that the Bootstrap standard uses "slide" instead of "slideStart". We decided to deviate from the standard in order to improved legibility of the code.

To get familiar with BootsFaces AJAX, try the BootsFaces AJAX demo project.

The disabled attribute

The disabled attribute works a bit different than in most components. It disables (or rather: hides) the controls of the carousel. It still rotates the slides (if you configure it so), but the user can't influence that. AJAX and JavaScript events are processed no matter if the carousel is disabled or not.

Do it yourself

If you need more flexibility than b:carousel offers, the W3C example shows how to do it yourself. Since v1.0.0, you don't need to load carousel CSS, since it is included in the core CSS of default, Bootswatch and PatternFly themes.



Attribute Default value Description
action (none) The button action, this can be method expression or a string outcome.
action-listener
actionListener (alternative writing)
(none) A method expression that refers to a method with this signature: void methodName(Action-Event).
active-index
activeIndex (alternative writing)
0 Optional attribute to define which slide is active initially.
ajax false Whether the Button submits the form with AJAX.
col-lg
colLg (alternative writing)
-1 Integer value to specify how many columns to span on large screens (≥1200 pixels wide). The number may optionally be followed by "column" or "columns". Alternative legal values: half, one-third, two-thirds, one-fourth, three-fourths.
col-md
colMd (alternative writing)
-1 Integer value to specify how many columns to span on medium screens (≥992 pixels wide). The number may optionally be followed by "column" or "columns". Alternative legal values: half, one-third, two-thirds, one-fourth, three-fourths.
col-sm
colSm (alternative writing)
-1 Integer value to specify how many columns to span on small screens (≥768p pixels wide). The number may optionally be followed by "column" or "columns". Alternative legal values: half, one-third, two-thirds, one-fourth, three-fourths.
col-xs
colXs (alternative writing)
-1 Integer value to specify how many columns to span on tiny screens (≤ 767 pixels wide). The number may optionally be followed by "column" or "columns". Alternative legal values: half, one-third, two-thirds, one-fourth, three-fourths.
disabled false Boolean value to specify if the button is disabled.
display block If you use the "visible" attribute, the value of this attribute is added. Legal values: block, inline, inline-block. Default: block.
hidden (none) This column is hidden on a certain screen size and below. Legal values: lg, md, sm, xs.
id (none) Unique identifier of the component in a namingContainer.
interval 5000 Specifies the delay (in milliseconds) between each slide.
large-screen
largeScreen (alternative writing)
-1 Alternative spelling to col-lg. Integer value to specify how many columns to span on large screens (≥1200 pixels wide). The number may optionally be followed by "column" or "columns". Alternative legal values: half, one-third, two-thirds, one-fourth, three-fourths.
medium-screen
mediumScreen (alternative writing)
-1 Alternative spelling to col-md. Integer value to specify how many columns to span on medium screens (≥992 pixels wide). The number may optionally be followed by "column" or "columns". Alternative legal values: half, one-third, two-thirds, one-fourth, three-fourths.
offset (none) Integer value to specify how many columns to offset.
offset-lg
offsetLg (alternative writing)
(none) Integer value to specify how many columns to offset.
offset-md
offsetMd (alternative writing)
(none) Integer value to specify how many columns to offset.
offset-sm
offsetSm (alternative writing)
(none) Integer value to specify how many columns to offset.
offset-xs
offsetXs (alternative writing)
(none) Integer value to specify how many columns to offset.
onclick (none) The onclick attribute.
oncomplete (none) JavaScript to be executed when ajax completes with success.
ondblclick (none) Client side callback to execute when input element is double clicked.
onmousedown (none) Client side callback to execute when a pointer input element is pressed down over input element.
onmousemove (none) Client side callback to execute when a pointer input element is moved within input element.
onmouseout (none) Client side callback to execute when a pointer input element is moved away from input element.
onmouseover (none) Client side callback to execute when a pointer input element is moved onto input element.
onmouseup (none) Client side callback to execute when a pointer input element is released over input element.
onslid (none) Client side callback to execute when the carousel just finished sliding to another item.
onslidestart (none) Client side callback to execute when the carousel start to slide to another item.
pause hover Pauses the carousel from going through the next slide when the mouse pointer enters the carousel, and resumes the sliding when the mouse pointer leaves the carousel. Set pause to false to stop the ability to pause on hover.
process (none) Comma or space separated list of ids or search expressions denoting which values are to be sent to the server.
rendered false Boolean value to specify the rendering of the component, when set to false the component will not be rendered.
show-controls
showControls (alternative writing)
true adds 'left' and 'right' buttons that allows the user to go back and forth between the slides manually
show-indicators
showIndicators (alternative writing)
true The indicators are the little dots at the bottom of each slide (which indicates how many slides there are in the carousel, and which slide the user are currently viewing).
slide true Tells Bootstrap to show new items by sliding them into view
small-screen
smallScreen (alternative writing)
-1 Alternative spelling to col-sm. Integer value to specify how many columns to span on small screens (≥768p pixels wide). The number may optionally be followed by "column" or "columns". Alternative legal values: half, one-third, two-thirds, one-fourth, three-fourths.
span (none) Integer value to specify how many columns to span on medium screens (≥992 pixels). The number may optionally be followed by "column" or "columns". Alternative legal values: half, one-third, two-thirds, one-fourth, three-fourths.
start-animation
startAnimation (alternative writing)
true tells Bootstrap to begin animating the carousel immediately when the page loads.
style (none) Inline style of the input element.
style-class
styleClass (alternative writing)
(none) Style class of this element.
tiny-screen
tinyScreen (alternative writing)
-1 Alternative spelling to col-xs. Integer value to specify how many columns to span on tiny screens (≤ 767 pixels wide). The number may optionally be followed by "column" or "columns". Alternative legal values: half, one-third, two-thirds, one-fourth, three-fourths.
tooltip (none) The text of the tooltip.
tooltip-container
tooltipContainer (alternative writing)
body Where is the tooltip div generated? That's primarily a technical value that can be used to fix rendering errors in special cases. Also see data-container in the documentation of Bootstrap. The default value is body.
tooltip-delay
tooltipDelay (alternative writing)
0 The tooltip is shown and hidden with a delay. This value is the delay in milliseconds. Defaults to 0 (no delay).
tooltip-delay-hide
tooltipDelayHide (alternative writing)
0 The tooltip is hidden with a delay. This value is the delay in milliseconds. Defaults to 0 (no delay).
tooltip-delay-show
tooltipDelayShow (alternative writing)
0 The tooltip is shown with a delay. This value is the delay in milliseconds. Defaults to 0 (no delay).
tooltip-position
tooltipPosition (alternative writing)
(none) Where is the tooltip to be displayed? Possible values: "top", "bottom", "right", "left", "auto", "auto top", "auto bottom", "auto right" and "auto left". Default to "bottom".
update (none) Component(s) to be updated with ajax.
visible (none) This column is shown on a certain screen size and above. Legal values: lg, md, sm, xs.
wrap true Specifies whether the carousel should go through all slides continuously, or stop at the last slide.
Attribute Default value Description
action (none) The button action, this can be method expression or a string outcome.
action-listener
actionListener (alternative writing)
(none) A method expression that refers to a method with this signature: void methodName(Action-Event).
active false Optional attribute to define which slide is active initially.
ajax false Whether the Button submits the form with AJAX.
caption (none) Optional caption, which is embedded in an h3 tag. If you need more flexibility, add an carouselCaption child tag. If you don't need a caption, omit both.
disabled false Boolean value to specify if the button is disabled.
id (none) Unique identifier of the component in a namingContainer.
onclick (none) The onclick attribute.
oncomplete (none) JavaScript to be executed when ajax completes with success.
ondblclick (none) Client side callback to execute when input element is double clicked.
onmousedown (none) Client side callback to execute when a pointer input element is pressed down over input element.
onmousemove (none) Client side callback to execute when a pointer input element is moved within input element.
onmouseout (none) Client side callback to execute when a pointer input element is moved away from input element.
onmouseover (none) Client side callback to execute when a pointer input element is moved onto input element.
onmouseup (none) Client side callback to execute when a pointer input element is released over input element.
process (none) Comma or space separated list of ids or search expressions denoting which values are to be sent to the server.
rendered false Boolean value to specify the rendering of the component, when set to false the component will not be rendered.
style (none) Inline style of the input element.
style-class
styleClass (alternative writing)
(none) Style class of this element.
tooltip (none) The text of the tooltip.
tooltip-container
tooltipContainer (alternative writing)
body Where is the tooltip div generated? That's primarily a technical value that can be used to fix rendering errors in special cases. Also see data-container in the documentation of Bootstrap. The default value is body.
tooltip-delay
tooltipDelay (alternative writing)
0 The tooltip is shown and hidden with a delay. This value is the delay in milliseconds. Defaults to 0 (no delay).
tooltip-delay-hide
tooltipDelayHide (alternative writing)
0 The tooltip is hidden with a delay. This value is the delay in milliseconds. Defaults to 0 (no delay).
tooltip-delay-show
tooltipDelayShow (alternative writing)
0 The tooltip is shown with a delay. This value is the delay in milliseconds. Defaults to 0 (no delay).
tooltip-position
tooltipPosition (alternative writing)
(none) Where is the tooltip to be displayed? Possible values: "top", "bottom", "right", "left", "auto", "auto top", "auto bottom", "auto right" and "auto left". Default to "bottom".
update (none) Component(s) to be updated with ajax.
Attribute Default value Description
action (none) The button action, this can be method expression or a string outcome.
action-listener
actionListener (alternative writing)
(none) A method expression that refers to a method with this signature: void methodName(Action-Event).
ajax false Whether the Button submits the form with AJAX.
disabled false Boolean value to specify if the button is disabled.
id (none) Unique identifier of the component in a namingContainer.
onclick (none) The onclick attribute.
oncomplete (none) JavaScript to be executed when ajax completes with success.
ondblclick (none) Client side callback to execute when input element is double clicked.
onmousedown (none) Client side callback to execute when a pointer input element is pressed down over input element.
onmousemove (none) Client side callback to execute when a pointer input element is moved within input element.
onmouseout (none) Client side callback to execute when a pointer input element is moved away from input element.
onmouseover (none) Client side callback to execute when a pointer input element is moved onto input element.
onmouseup (none) Client side callback to execute when a pointer input element is released over input element.
process (none) Comma or space separated list of ids or search expressions denoting which values are to be sent to the server.
rendered false Boolean value to specify the rendering of the component, when set to false the component will not be rendered.
style (none) Inline style of the input element.
style-class
styleClass (alternative writing)
(none) Style class of this element.
tooltip (none) The text of the tooltip.
tooltip-container
tooltipContainer (alternative writing)
body Where is the tooltip div generated? That's primarily a technical value that can be used to fix rendering errors in special cases. Also see data-container in the documentation of Bootstrap. The default value is body.
tooltip-delay
tooltipDelay (alternative writing)
0 The tooltip is shown and hidden with a delay. This value is the delay in milliseconds. Defaults to 0 (no delay).
tooltip-delay-hide
tooltipDelayHide (alternative writing)
0 The tooltip is hidden with a delay. This value is the delay in milliseconds. Defaults to 0 (no delay).
tooltip-delay-show
tooltipDelayShow (alternative writing)
0 The tooltip is shown with a delay. This value is the delay in milliseconds. Defaults to 0 (no delay).
tooltip-position
tooltipPosition (alternative writing)
(none) Where is the tooltip to be displayed? Possible values: "top", "bottom", "right", "left", "auto", "auto top", "auto bottom", "auto right" and "auto left". Default to "bottom".
update (none) Component(s) to be updated with ajax.
Attribute Default value Description
action (none) The button action, this can be method expression or a string outcome.
action-listener
actionListener (alternative writing)
(none) A method expression that refers to a method with this signature: void methodName(Action-Event).
ajax false Whether the Button submits the form with AJAX.
direction (none) Can take one of the values 'left' and 'right'. Determines whether the carousel scrolls to the next or to the previous image.
disabled false Boolean value to specify if the button is disabled.
id (none) Unique identifier of the component in a namingContainer.
onclick (none) The onclick attribute.
oncomplete (none) JavaScript to be executed when ajax completes with success.
ondblclick (none) Client side callback to execute when input element is double clicked.
onmousedown (none) Client side callback to execute when a pointer input element is pressed down over input element.
onmousemove (none) Client side callback to execute when a pointer input element is moved within input element.
onmouseout (none) Client side callback to execute when a pointer input element is moved away from input element.
onmouseover (none) Client side callback to execute when a pointer input element is moved onto input element.
onmouseup (none) Client side callback to execute when a pointer input element is released over input element.
process (none) Comma or space separated list of ids or search expressions denoting which values are to be sent to the server.
rendered false Boolean value to specify the rendering of the component, when set to false the component will not be rendered.
style (none) Inline style of the input element.
style-class
styleClass (alternative writing)
(none) Style class of this element.
tooltip (none) The text of the tooltip.
tooltip-container
tooltipContainer (alternative writing)
body Where is the tooltip div generated? That's primarily a technical value that can be used to fix rendering errors in special cases. Also see data-container in the documentation of Bootstrap. The default value is body.
tooltip-delay
tooltipDelay (alternative writing)
0 The tooltip is shown and hidden with a delay. This value is the delay in milliseconds. Defaults to 0 (no delay).
tooltip-delay-hide
tooltipDelayHide (alternative writing)
0 The tooltip is hidden with a delay. This value is the delay in milliseconds. Defaults to 0 (no delay).
tooltip-delay-show
tooltipDelayShow (alternative writing)
0 The tooltip is shown with a delay. This value is the delay in milliseconds. Defaults to 0 (no delay).
tooltip-position
tooltipPosition (alternative writing)
(none) Where is the tooltip to be displayed? Possible values: "top", "bottom", "right", "left", "auto", "auto top", "auto bottom", "auto right" and "auto left". Default to "bottom".
update (none) Component(s) to be updated with ajax.
