Image (<b:image />) since 0.8.0

The <b:image /> component is just that: an image. Plus the unified AJAX engine of BootsFaces, and Bootstrap tooltips.

Basic usage

Alternatively, you can use the JSF resource libraries, just the way you're used to from <h:graphicImage />;

Advanced usage

You can use the standard JavaScript callbacks to call both JavaScript function and Java methods (via AJAX). See BootsFaces chess for a full-blown demo. These following demonstrate how BootsFaces chess uses AJAX to implement drag and drop:

Don't use both value and name/library

Until BootsFaces 0.8.5, there was an error in the documentation which lead some developers to use both name and value. Both attributes belong to different resource loading mechanisms, so this caused RES_NOT_FOUND errors. Since BootsFaces 0.8.6, the value attributes is evaluated first. If both attributes are provided, BootsFaces displays a warning in the logfile (only in the development stage).

Responsive attributes since 0.9.0

The image supports the full range of responsive attributes, such as col-*, visible and hidden:

Reference section

Attribute Default value Description
ajax false Activates AJAX. The default value is false (no AJAX).
alt (none) Alternate textual description of the element rendered by this component.
binding (none) An EL expression referring to a server side UIComponent instance in a backing bean.
col-lg
colLg (alternative writing)
-1 Integer value to specify how many columns to span on large screens (≥1200 pixels wide). The number may optionally be followed by "column" or "columns". Alternative legal values: half, one-third, two-thirds, one-fourth, three-fourths.
col-md
colMd (alternative writing)
-1 Integer value to specify how many columns to span on medium screens (≥992 pixels wide). The number may optionally be followed by "column" or "columns". Alternative legal values: half, one-third, two-thirds, one-fourth, three-fourths.
col-sm
colSm (alternative writing)
-1 Integer value to specify how many columns to span on small screens (≥768p pixels wide). The number may optionally be followed by "column" or "columns". Alternative legal values: half, one-third, two-thirds, one-fourth, three-fourths.
col-xs
colXs (alternative writing)
-1 Integer value to specify how many columns to span on tiny screens (≤ 767 pixels wide). The number may optionally be followed by "column" or "columns". Alternative legal values: half, one-third, two-thirds, one-fourth, three-fourths.
disabled false Boolean value to specify if the button is disabled.
display block If you use the "visible" attribute, the value of this attribute is added. Legal values: block, inline, inline-block. Default: block.
height (none) Override for the height of this image.
hidden (none) This column is hidden on a certain screen size and below. Legal values: lg, md, sm, xs.
id (none) Unique identifier of the component in a namingContainer.
immediate false Flag indicating that, if this component is activated by the user, notifications should be delivered to interested listeners and actions immediately (that is, during Apply Request Values phase) rather than waiting until Invoke Application phase. Default is false.
lang (none) Code describing the language used in the generated markup for this component.
large-screen
largeScreen (alternative writing)
-1 Alternative spelling to col-lg. Integer value to specify how many columns to span on large screens (≥1200 pixels wide). The number may optionally be followed by "column" or "columns". Alternative legal values: half, one-third, two-thirds, one-fourth, three-fourths.
library (none) The name of the folder in the JSF resource library. Alternatively, you can specify the file name directly using the 'value' attribute.
medium-screen
mediumScreen (alternative writing)
-1 Alternative spelling to col-md. Integer value to specify how many columns to span on medium screens (≥992 pixels wide). The number may optionally be followed by "column" or "columns". Alternative legal values: half, one-third, two-thirds, one-fourth, three-fourths.
name (none) The name of the icon in the JSF resource library. Alternatively, you can specify the file name directly using the 'value' attribute.
offset (none) Integer value to specify how many columns to offset.
offset-lg
offsetLg (alternative writing)
(none) Integer value to specify how many columns to offset.
offset-md
offsetMd (alternative writing)
(none) Integer value to specify how many columns to offset.
offset-sm
offsetSm (alternative writing)
(none) Integer value to specify how many columns to offset.
offset-xs
offsetXs (alternative writing)
(none) Integer value to specify how many columns to offset.
onclick (none) Client side callback to execute when input element is clicked.
oncomplete (none) JavaScript to be executed when ajax completes with success.
ondblclick (none) Client side callback to execute when input element is double clicked.
ondragover (none) Client side callback when an element is dragged over another element. Call event.preventDefault() to allow the dragged element to drop. May also call an AJAX function.
ondragstart (none) Client side callback when a drag-and-drop action starts. May also call an AJAX function.
ondrop (none) Client side callback when a drag-and-drop action ends. May also call an AJAX function.
onmousedown (none) Client side callback to execute when a pointer input element is pressed down over input element.
onmousemove (none) Client side callback to execute when a pointer input element is moved within input element.
onmouseout (none) Client side callback to execute when a pointer input element is moved away from input element.
onmouseover (none) Client side callback to execute when a pointer input element is moved onto input element.
onmouseup (none) Client side callback to execute when a pointer input element is released over input element.
process (none) Comma or space separated list of ids or search expressions denoting which values are to be sent to the server.
readonly false Flag indicating that this input element will prevent changes by the user.
rendered false Boolean value to specify the rendering of the component, when set to false the component will not be rendered.
small-screen
smallScreen (alternative writing)
-1 Alternative spelling to col-sm. Integer value to specify how many columns to span on small screens (≥768p pixels wide). The number may optionally be followed by "column" or "columns". Alternative legal values: half, one-third, two-thirds, one-fourth, three-fourths.
span (none) Integer value to specify how many columns to span on medium screens (≥992 pixels). The number may optionally be followed by "column" or "columns". Alternative legal values: half, one-third, two-thirds, one-fourth, three-fourths.
style (none) Inline style of the input element.
style-class
styleClass (alternative writing)
(none) Style class of this element.
tiny-screen
tinyScreen (alternative writing)
-1 Alternative spelling to col-xs. Integer value to specify how many columns to span on tiny screens (≤ 767 pixels wide). The number may optionally be followed by "column" or "columns". Alternative legal values: half, one-third, two-thirds, one-fourth, three-fourths.
title (none) Advisory title information about markup elements generated for this component.
tooltip (none) The text of the tooltip.
tooltip-container
tooltipContainer (alternative writing)
body Where is the tooltip div generated? That's primarily a technical value that can be used to fix rendering errors in special cases. Also see data-container in the documentation of Bootstrap. The default value is body.
tooltip-delay
tooltipDelay (alternative writing)
0 The tooltip is shown and hidden with a delay. This value is the delay in milliseconds. Defaults to 0 (no delay).
tooltip-delay-hide
tooltipDelayHide (alternative writing)
0 The tooltip is hidden with a delay. This value is the delay in milliseconds. Defaults to 0 (no delay).
tooltip-delay-show
tooltipDelayShow (alternative writing)
0 The tooltip is shown with a delay. This value is the delay in milliseconds. Defaults to 0 (no delay).
tooltip-position
tooltipPosition (alternative writing)
(none) Where is the tooltip to be displayed? Possible values: "top", "bottom", "right", "left", "auto", "auto top", "auto bottom", "auto right" and "auto left". Default to "bottom".
update (none) Component(s) to be updated with ajax.
value (none) The file name of this image. Alternatively, you can use the attributes 'library' and 'name' to use the JSF resource library.
visible (none) This column is shown on a certain screen size and above. Legal values: lg, md, sm, xs.
width (none) Override for the width of this image.

BootsFaces generates pretty simple code for the <b:image>. In particular, there's no extra CSS class. You can modify the appearance of the image using the standard JSF attributes styleClass and style.
